Drive

  • Signal for Docs
  • Tech, Features, Challenges, Designs

Tech

Links

Features

  • Direct P2P or Offline
  • Multiple Devices
  • QR Codes for invites
  • Document Validation

Challenges

  • docs are big
  • adding devices
    • sharing more than a few bytes: Rendezvous
  • keyhive problems
    • serialize methods
    • transitive roles
  • schema designed for concurrency

Design

  • Relay
  • UI/Worker
  • Doc format

Design:Relay

  • 2 channels
    • peer-matched (keyhive)
    • rendezvous (invites)
  • evolved:
    1. public
    2. all-to-all (let peers decide)
    3. match groupid & watch list
    4. future: HMAC rotation

Adding a Device

  • A user is a group of devices, each its own keyhive key
  • The QR carries a rendezvous id and the key to decrypt it

Adding a Device


Design:Browser

  • open all docs? No
  • main
    • UI
    • partial doc (jq subscription)
    • serialize mutations
  • worker
    • all state
    • network, opens docs, sends qupdate

Design:Documents

  • validate every change
  • schema checks interdeps
  • sheet challenges
    • from =SUM(Sheet2!A1:$A$10)
    • to =SUM({R[xxx]C[yyy]S{zzz}}:{R{www}C{yyy}S{zzz}})

Thanks!

Links

Screen caps

The rest of slides are screencaps

Adding a device

  • 2 channels
    • peer-matched (keyhive)
    • rendezvous (invites)
  • evolved:
    1. public
    2. all-to-all (let peers decide)
    3. match groupid & watch list
    4. future: HMAC rotation

Adding a friend

  • Same QR, other direction: the invite carries a document
  • Sharing names a role; the member list is the access

Presence updates (spreadsheet)

  • Both peers pan and select freely; each sees the other's cell outlined and tagged, in that peer's own colour
  • Whole rows highlight from the headers; a formula, opened, outlines every cell it depends on in the colour of its own token
  • Edit that formula and every figure derived from it moves on both screens — formatting and conditional formatting are one sheet away

Presence updates (peritext doc)

  • A caret is an Automerge cursor, not an offset — it names a character, so it survives someone else's edit
  • Both peers select, and the two selections overlap — each sees the other's tagged with their name
  • Alice types over hers, destroying the words they shared: Bob is left holding the ones that survived, not a collapsed caret
  • Positions resolve in the same worker push as the text they describe, so a caret is never a frame stale

Source editing

  • Underneath it is all JSON, so the raw editor is one more view over the same tree
  • The dot tracks the peer's selected cell, because presence is a path rather than a coordinate
  • Cells are sparse, so typing into an empty one creates the key — it appears in the other pane mid-list

- Automerge is the CRDT; Peritext is the rich-text half of it, which is what makes a caret survive someone else's edit - Keyhive is the encryption and access layer: devices, groups, documents, roles - The relay is stateless and never holds plaintext — it introduces peers and forwards opaque bytes

- Peers upgrade to a direct WebRTC channel when they can, and fall back to the relay when they cannot - A user is a group of their devices, so sharing with a person shares with every device they own - Five document types, each with a schema — calendar, tasks, counters, spreadsheet, prose

- A QR code holds a few hundred bytes; the keyhive material to link a device is tens of kilobytes, hence the rendezvous channel - Keyhive gaps that had to be filled: freshly rotated keys lived only in memory so a reload lost them; groups as members of groups, with access capped to the minimum along each path; an event per change so the app can persist and refresh - Roles are live delegations, so revoking one changes what the *other* device can do without asking it anything

- Each device declares its own user group plus the groups it knows (friends, doc co-members); the relay only introduces same-group devices and mutual watchers - Un-friending withdraws the match and the relay dissolves the pair — strangers sharing a relay never learn of each other - Group ids are self-asserted routing hints today; the HMAC daily token is designed and deferred

- The main thread is only UI; a worker owns local and remote updates (automerge, keyhive, transports) - The UI subscribes to small jq query slices, so it never holds a whole document in memory - Presence is a path into the document (e.g. ['events', uid, 'title']), never screen coordinates — so any view can render it, and it is encrypted with the document's own key - The relay never stores messages for later delivery, so the always-online peer cycles through documents looking for updates

- Every doc type has a schema covering structure *and* data dependencies — due dates, formula references, cell keys must all resolve - Shapes are chosen *for* the CRDT: id-keyed maps instead of arrays, fractional indices for order - Formulas reference row/column ids, so reordering never rewrites them — that is what the second form buys - Validation runs on local and remote changes alike, and errors are advisory rather than a block

- The relay routes rendezvous by channel id and never sees plaintext; this is the one path a device with no group yet can use, since it has nothing to be introduced by - Both directions are sealed under the same key — the bundle crossing back is the phone's own card - The highlighted row is the moment the new device has access to anything - Then it is just a peer: the phone re-announces its group, the relay's same-group rule pairs the sockets, and the document list is whatever keyhive says it can reach

- Once the exchange is done both sides are ordinary peers, which is what this diagram is: announce, get paired, sync keyhive, and the reachable documents follow - Document ids were never in the QR payload — the new peer asks keyhive what it can reach - Content only flows because keyhive says it may; the relay is forwarding ciphertext it cannot read either way
